Product types: Network receiver, AV receiver
Series: Pioneer SC
Speaker configuration: 9.2
Power per channel: 185 Watt
Technical specifications
Output power: 760 Watt
Output impedance: 8 Ohm
Speaker connection: Screw terminals
Construction: Digital power amplifiers
HDMI version: HDMI 2.0
Connections
analog audio inputs: 4x Line In (Cinch/RCA, Stereo), 1x MM Phono In (Cinch/RCA, Stereo)
analog audio outputs: Zone 2 (LINE Out, Cinch/RCA, Stereo), Zone 3 (LINE Out, Cinch/RCA, Stereo), 1x LINE Out (Cinch/RCA, Stereo)
digital audio inputs: 3x S/PDIF IN (TOS-Link optical), 2x S/PDIF IN (Cinch/RCA coaxial)
HDMI ports: HDMI-ARC, 2x HDMI Out, 7x HDMI In
Video Connections: 2x Component In, 2x Composite In
Preamp outputs: 2x Subwoofer (Cinch/RCA)
Front Connections: HDMI Input, 1x USB 2.0 Type-A, Headphone Output, 1x Measurement Microphone (Setup Mic)
Data connection: 1x Network (Ethernet)
Connections for control signals: RS-232, 1x 12V Trigger OUT, 1x Remote OUT, 1x Remote IN, 1x 12V Trigger IN
additional connection: Antenna connection
gold-plated connectors: no
Audio
Audio functions: IMAX Enhanced, DSD audio compatible
Dolby Formats: Dolby TrueHD, Dolby Surround, Dolby Digital Plus, Dolby Atmos
DTS Formats: DTS HD Master Audio, DTS HD High Resolution Audio, DTS ES, DTS:X, DTS Neural:X, DTS 96/24, DTS HD Express, DTS Express
THX Formats: THX Ultra 2 Plus
Number of listening zones: 3
Video
Supported Resolutions: 4K (2160p), 1080p
Video Functions: Deep Color, x.v.Color, 4K Pass-Through, BT.2020 Support, HDCP 2.2, High Dynamic Range (HDR), HDMI Standby Input Switching
3D-Ready: yes
Connectivity
Network functions: Control via App
Wireless transmissions: Fire Connect, AirPlay 2, AirPlay, Chromecast, Bluetooth, Wi-Fi
Streaming Services: Deezer, TuneIn, Spotify, Tidal, Amazon Music, Internet Radio
USB interface: yes
Functions
Comfort features: Graphical User Interface (GUI)
Environmental properties: Sleep Timer, Auto-Off, Standby Passthrough
automatic measurement: yes
Calibration systems: MCACC Pro, MCACC
with remote control: yes
Reception areas: FM (VHF), AM (MW)
Number of station presets: 40
Smart Home
Voice assistant: Google Assistant
further properties
Dimensions: 435 x 185 x 441 mm
Weight: 15,3 kg
Enclosure feature: Metal
Color: black
