Product types: Network receiver, AV receiver
Speaker configuration: 9.2
Power per channel: 185 Watt
Technical specifications
Output power: 1.665 Watt
Output impedance: 6 Ohm
Speaker connection: Screw clamps
maximum sample rate: 384 kHz
Bitrate: 32 Bit
Constructions: Digital signal processor (DSP), digital power amplifiers
Connections
analog audio inputs: 4x Line In (Cinch/RCA, Stereo), 1x MM Phono In (Cinch/RCA, Stereo)
analog audio outputs: Zone 2 (LINE Out, Cinch/RCA, Stereo), Zone 3 (LINE Out, Cinch/RCA, Stereo), 1x LINE Out (Cinch/RCA, Stereo)
digital audio inputs: 1x S/PDIF IN (RCA coaxial), 2x S/PDIF IN (TOSLINK optical)
HDMI ports: HDMI-ARC, 2x HDMI Out, 7x HDMI In
Video Connections: 1x Component IN, 2x Composite IN
Preamp outputs: 2x Subwoofer (Cinch/RCA)
Front Connectors: HDMI Input, 1x USB 2.0 Type-A, Headphone Output, 1x Measurement Microphone (Setup Mic)
Data connections: 1x Network (Ethernet), 2x USB 2.0
Connections for control signals: RS-232, 1x Remote OUT, 2x 12V Trigger OUT, 1x Remote IN
additional connection: Antenna connection
gold-plated connectors: no
Audio
Audio functions: DSD-Audio compatible
Dolby Formats: Dolby TrueHD, Dolby Surround, Dolby Digital Plus, Dolby Atmos
DTS Formats: DTS HD Master Audio, DTS HD High Resolution Audio, DTS ES, DTS:X, DTS Neural:X, DTS 96/24, DTS HD Express
Number of listening zones: 3
Video
Supported Resolutions: 4K (2160p), 1080p
Video Functions: Deep Color, x.v.Color, 4K Pass-Through, HDMI Standby Through, HLG (Hybrid Log Gamma), Dolby Vision, BT.2020 Support, HDCP 2.2, High Dynamic Range (HDR), HDMI Standby Input Switching
3D-Ready: yes
Connectivity
Network functions: Control via App, Audio Streaming, Network Streaming
Wireless Transmissions: Fire Connect, AirPlay, Chromecast, DTS Play-Fi, Bluetooth, Wi-Fi
Streaming Services: Deezer, TuneIn, Spotify, Tidal, Amazon Music, Internet Radio
USB interface: yes
Functions
Comfort features: Graphical User Interface (GUI)
Environmental properties: Sleep Timer, Auto Shutoff, Standby Pass Through
automatic measurement: yes
Measurement System: MCACC
with remote control: yes
Reception areas: FM (FM), AM (AM)
Number of Tuner Storage: 40
Smart Home
Language Assistant: Google Assistant
further properties
Dimensions: 435 x 173 x 370,5 mm
Weight: 10,8 kg
Enclosure properties: Metal
Color: black
