Camera types: IP Camera, Infrared Camera
Series: TP-Link VIGI
Equipment
Equipment: with integrated speaker, with integrated lamp, with microphone
Functions: Alarm Function, Password Protection, Cloud Function, IP Address Filter, Motion Detection, Region of Interest (ROI), IR-Cut Filter, with IR-LEDs, Day and Night Function, with Notification Function
Audio function: 2-way audio
Video Functions: with night vision function, with live viewing, with vehicle detection, with person detection, with video stream
supported memory cards: microSD
Connections: 5.5 mm Coaxial, RJ-45 PoE
Ppower supply: PoE (Power over Ethernet), DC 12 V
Housing
Housing color: white
Mounting types: Wall mounting, Ceiling mounting, Surface mounting
Application area: inside
Rotatable 360°: yes
Swivel range: 360 degrees
Tilt range: 85 °
Temperature range: -30 to 60 °C
Weight: 240 g
Dimensions (W x H x D): 123 x 123 x 84 mm
Network
Interfaces: RJ45, 802.3af (Power over Ethernet)
LAN standard: Ethernet 10/100
System Requirements Software: Firefox, Safari, Chrome, Edge
Protocols: TCP/IP, UDP, ICMP, DHCP, HTTP, HTTPS, SSL/TLS, NTP, DNS, RTSP, ONVIF Profile S, UPnP UDP
Lens
Objective focal length: 2,8 mm
Lens properties: fixed focal length
Lens mount: Lens mount
Light sensitivity IR: 0 Lux
Light sensitivity without IR: 0.005 Lux
Video & Image
Infrared range: 30 m
Number of infrared LEDs: 2
Resolution: 2880 x 1620 pixels
Images per second.: 5, 30, 10, 15, 20, 25, 1
horizontal field of view: 109°
vertical field of view: 57 °C
diagonal field of view: 128 degrees
Sensor Type: 1/2.7" Progressive Scan CMOS
Image sensor: 5 Megapixel
Image enhancements: digital noise reduction (3D-DNR), backlight compensation (BLC), Wide Dynamic Range (WDR), high light compensation (HLC)
Video Formats: H.264, H.265, H.264+, H.265+
Video recording: Color
Audio Formats: G.711
Additional features
suitable for: Darkness
