Yamaha TSR-400

Product types: AV Receiver, Network Receiver
Speaker configuration: 5.2
Power per channel: 80 Watt

Technical specifications
Output impedance: 6 Ohm
Speaker connection: Screw terminals
maximum sample rate: 384 kHz
Bitrate: 32 Bit

Connections
analog audio input: 3x LINE In (RCA, Stereo)
digital audio inputs: 1x S/PDIF IN (Cinch/RCA coaxial)
digital audio output: 1x S/PDIF OUT (Cinch/RCA coaxial)
HDMI ports: HDMI-ARC, 4x HDMI In, 1x HDMI Out
Preamp outputs: 2x Subwoofer (Cinch/RCA)
Front Connections: Headphone output, 1x USB 2.0 Type-A, 1x measurement microphone (Setup Mic)
Data connection: 1x Network (Ethernet)

Audio
Audio functions: Pure Direct, High-Resolution Audio, Virtual CINEMA DSP, Dialog Enhancement, Virtual Presence Speaker, Compressed Music Enhancer, Adaptive DRC, Bi-wiring compatible
Dolby Formats: Dolby TrueHD, Dolby Digital Plus
DTS Format: DTS HD Master Audio
Number of listening zones: 2

Video
Video Functions: HDR10+, 4K Pass-Through, 8K Pass-Through

Connectivity
Network functions: Audio Streaming, App Control, Multiroom, Network Streaming
Wireless transmissions: Wi-Fi, Bluetooth, AirPlay
USB interface: yes
HDMI-CEC: yes

Functions
Comfort features: Graphical User Interface (GUI)
Environmental properties: Energy-saving mode, automatic shut-off
automatic measurement: yes
Measurement System: YPAO
with remote control: yes

Power supply
Power Consumption Standby: 0,1 Watt

Smart Home
Voice Assistants: Amazon Alexa, Google Assistant

further properties
Dimensions: 435 x 171 x 377 mm
Weight: 8,8 kg
Color: black
