Product types: AV Receiver, Stereo Receiver, Network Receiver
Series: Denon AV Receiver
Speaker configurations: A/B speaker connections, 7.2, 2.0
Power per channel: 145 Watt
Technical specifications
Output power: 7 x 145 Watt
Output impedance: 6 Ohm
Speaker connection: Screw terminals
Constructions: Discrete power amplifiers, 4Ω speaker support
HDMI version: HDMI 2.0
Playback formats: DSD, FLAC, ALAC, AIFF, WAV
Connections
analog audio inputs: 4x Line In (Cinch/RCA, Stereo), 1x MM Phono In (Cinch/RCA, Stereo)
digital audio inputs: 2x S/PDIF IN (TOS-Link optical)
HDMI ports: HDMI-ARC, 2x HDMI Out, 6x HDMI In
Video Connections: 1x Component Out, 1x Composite Out, 2x Component In, 2x Composite In
Preamp outputs: 2x Subwoofer (Cinch/RCA)
Front Connections: 1x USB 2.0 Type-A, headphone output, 1x measurement microphone (setup mic)
Data connections: 1x Network (Ethernet), 1x USB 2.0
additional connection: Antenna connection
gold-plated connectors: no
Audio
Audio functions: Compressed Audio Restorer, Multizone, High-Resolution Audio, Audyssey Dynamic Volume, Audyssey Dynamic EQ, D.D.S.C. HD Digital, Jitter Reduction, DSD Audio Compatible, Pure Direct
Dolby Formats: Dolby TrueHD, Dolby Surround, Dolby Atmos, Dolby Height Virtualization
DTS Formats: DTS HD Master Audio, DTS:X, DTS Neural:X, DTS Virtual:X
Number of listening zones: 2
Video
Supported Resolutions: 4K (2160p), 8K (4320p)
Video Functions: Deep Color, Video Equalizer, 4K Pass-Through, HLG (Hybrid Log Gamma), Dolby Vision, BT.2020 Support, ISF Image Calibration, HDCP 2.3, 8K Pass-Through, HDR10+
3D-Ready: yes
Connectivity
Network functions: Network Streaming, Control via App, Audio Streaming
Wireless transmissions: AirPlay 2, AirPlay, HEOS, Bluetooth, Wi-Fi
Streaming Services: Deezer, Napster, TuneIn, Spotify, Tidal, SoundCloud, Internet Radio
USB interface: yes
HDMI-CEC: yes
DLNA: yes
Functions
Comfort features: Color-coded speaker connections, installation assistant
Environmental properties: Energy-saving mode
automatic measurement: yes
Measurement System: Audyssey MultEQ
LipSync: yes
with remote control: yes
Reception areas: FM (FM), AM (AM)
RDS: yes
Power supply
Power consumption in operation: 430 Watt
Power Consumption Standby: 0,1 Watt
Smart Home
Language Assistants: Amazon Alexa, Apple Siri, Google Assistant
further properties
Dimensions: 434 x 167 x 339 mm
Weight: 9,5 kg
Color: black
