Product types: Network receiver, AV receiver
Series: Denon AVC
Speaker configurations: A/B Speaker Connections, 9.2
Power per channel: 180 Watt
Technical specifications
Output power: 1.620 Watt
Speaker connectors: Banana plugs suitable, screw terminals
Constructions: Discrete power amplifiers, 4Ω speaker support
Connections
analog audio inputs: 1x MM Phono In (Cinch/RCA, Stereo), 6x LINE In (Cinch/RCA, Stereo)
analog audio output: 1x LINE Out (Cinch/RCA, Stereo)
digital audio inputs: 2x S/PDIF IN (TOS-Link optical), 2x S/PDIF IN (Cinch/RCA coaxial)
HDMI ports: HDMI-ARC, 2x HDMI-Out, 8x HDMI-In
Video Connections: 1x Component OUT, 1x Composite OUT, 2x Component IN, 3x Composite IN
Preamp outputs: 11.2 Surround (Cinch/RCA)
Front Connectors: HDMI Input, 1x USB 2.0 Type-A, Headphone Output, 1x Measurement Microphone (Setup Mic)
Data connections: 1x Network (Ethernet), 1x USB 2.0
Connections for control signals: RS-232, 2x 12V Trigger OUT, 1x Remote OUT, 1x Remote IN
additional connection: Antenna connection
Audio
Audio functions: Compressed Audio Restorer, Multizone, Audyssey LFC, Audyssey Dynamic Volume, Audyssey Dynamic EQ, Multichannel Stereo, asynchronous USB transmission, bi-wiring compatible, IMAX Enhanced
Dolby Formats: Dolby TrueHD, Dolby Surround, Dolby Atmos
DTS Formats: DTS HD Master Audio, DTS:X, DTS Neural:X, DTS Virtual:X
Auro 3D: yes
Number of listening zones: 3
Video
Supported Resolutions: 4K (2160p), 8K (4320p)
Video Functions: Video Equalizer, 4K Pass-Through, HLG (Hybrid Log Gamma), Dolby Vision, ISF Image Calibration, High Dynamic Range (HDR), HDR10, HDR10+, HDCP 2.3, 8K Pass-Through
3D-Ready: yes
Connectivity
Network functions: Control via App
Wireless Transmissions: Bluetooth, Wi-Fi, HEOS, AirPlay 2
Streaming Services: Deezer, TuneIn, Spotify, Tidal, Amazon Music, Napster, Soundcloud
USB interface: yes
HDMI-CEC: yes
Universal Plug and Play (UPnP): yes
Functions
Comfort features: Graphical User Interface (GUI), Setup Assistant, two-line FL display, On-Screen Display (OSD)
Environmental properties: Sleep Timer, Auto Off, Power Save Mode, Standby Through
automatic measurement: yes
Measurement System: Audyssey MultEQ XT32
LipSync: yes
with remote control: yes
Power supply
Power consumption in operation: 900 Watt
Power Consumption Standby: 0,1 Watt
Smart Home
Language Assistants: Amazon Alexa, Google Assistant, Apple Siri
further properties
Dimensions: 434 x 195 x 482 mm
Case features: Metal, Metal Front
Color: black
